SK800 Mini Skid Steer
Your Job Just Got A Whole Lot Easier.
When your jobsites demand long-lasting durability and performance, you need the Ditch Witch SK800—the perfect mini skid steer for a variety of jobs large and small. This construction-grade machine is built for heavy-duty operation on a range or utility, landscaping and other underground construction tasks, giving you maximum power and durability while increasing your ROI. The toughest challenges are no match for the versatile SK800.
SK800
Power
An efficient, low-maintenance 24.8-hp (18.5-kW) Kubota diesel engine provides exceptional power to all machine functions.
With an 911-lb (413-kg) rated operating capacity and an 83-inch (210.82-cm) hinge-pin height, the SK800 enables productive loading and the ability to handle heavy-duty tasks.
Equipped with 4.8-mph (7.7-km/h) ground drive speed in both forward and reverse for enhanced jobsite efficiency.
Accepts a variety of attachments for a wide range of utility, landscaping, plumbing and other underground construction tasks, improving customer ROI.
SK800
Rugged, Low-Maintenance Design
The rugged, construction-grade design is built for heavy-duty operation, improving machine durability, longevity and overall machine ROI.
An innovative high-drive track system features bolt-on sprockets and wide track rollers for enhanced stability, longer track life and ease of maintenance.
Low-maintenance, track-tensioning system is equipped with a grease cylinder for easy adjustment and track removal, improving machine longevity and minimizing downtime.
SK800
Operator’s Station
Designed specifically with the hardworking operator in mind, the SK800 is equipped with a best-in-class, 332-in2 (2141-cm2) operator platform for outstanding comfort and productivity during long hours on the job.
A spring-supported platform is integrated directly into the machine for enhanced durability and comfortability on the job.
Ergonomic operator's station comes standard with dual-lever ground drive controls and an optional joystick, allowing the operator to control each track independently for improved maintenance and mobility on difficult jobsite conditions.
An LCD display with programming improvements provides direct visibility into engine diagnostics.
SK800
Productivity
Industry-leading power to the attachment provides unbeatable productivity, especially when operating hydraulic attachments, and increases jobsite cycle times.
Advanced attachment-latching system for simple, secure connection of the attachments.
A two-way, easy-to-use auxiliary control foot pedal enables operators to maintain hydraulic flow to the attachment while freeing their hands to control depth and ground speed.
A single-point, lockable fuel and hydraulic fluid tank improve security and provide rental companies peace of mind.
SK800
Superior Customer Support
The SK800 leverages the common design and standard operation of other Ditch Witch skid steer models to streamline operator training and simplify machine maintenance.
As with all Ditch Witch equipment, the SK800 is backed by a worldwide network of dealerships you can count on for unmatched commitment to your success. From genuine Ditch Witch parts to factory-trained service and expert advice, your Ditch Witch dealership is your trusted partner on any job.
From the basics of HDD and vacs to the specifics of operating stand-on skid steers, trenchers and more, the Ditch Witch organization is your go-to resource for the best training in the industry. Talk to your local dealer to learn more about our Ditch Witch Certified Training programs.
Specifications
DIMENSIONS (STD)
| DIMENSIONS (STD) | U.S. | METRIC | |
|---|---|---|---|
| Operating height, max std. bucket | 105 in | 2.67 m | |
| Overall height of machine | 57 in | 1.45 m | |
| Overall length of machine, std. bucket | 105 in | 2.67 m | |
| Overall length of loader, no attachment | 86 in | 2.19 m | |
| Machine weight, no attachment, fluids full | 2,920 lb | 1324 kg | |
| Hinge pin height, max | 83 in | 2.10 m | |
| Wheelbase/track length | 43 in | 1.09 m | |
| Machine width | |||
| Max, w/9-in (230-mm) tracks | 42 in | 107 cm | |
| Min, w/7-in (180-mm) tracks | 36 in | 91 cm | |
| Ground clearance, min | |||
| Center | 8.9 in | 226 mm | |
| Side | 3.7 in | 94 mm | |
| Rated operating capacity | |||
| 35% of tipping capacity | 911 lb | 413 kg | |
| Tipping capacity | 2,605 lb | 1,182 kg | |
| Angle of departure | 27° |
POWER
| POWER | |||
|---|---|---|---|
| Engine | Kubota® D1105 | ||
| Fuel | Diesel | ||
| Gross power rating (SAE J1995) | 24.8 hp | 18.5 kW | |
| Emissions compliance | EPA Tier 4 | ||
| Number of cylinders | 3 | ||
| Displacement | 68.5 in3 | 1.12 L | |
| Bore | 3.07 in | 78 mm | |
| Stroke | 3.09 in | 78.4 mm | |
| Rated speed | 3,000 rpm |
OPERATION
| OPERATION | Ground drive speed | ||
|---|---|---|---|
| Forward/reverse | 4.3 mph | 6.9 km/h | |
| Ground pressure | |||
| 7-in (180-mm) tracks | 5.2 psi | 0.36 bar | |
| 9-in (230-mm) tracks | 4.3 psi | 0.29 bar |
HYDRAULIC SYSTEM
| HYDRAULIC SYSTEM | |||
|---|---|---|---|
| Auxiliary circuit | |||
| Double gear pump | |||
| Flow rate | 12.0 gpm | 45.4 l/min | |
| Pressure | 3,000 psi | 207 bar |
FLUID CAPACITIES
| FLUID CAPACITIES | |||
|---|---|---|---|
| Fuel tank capacity | 10.5 gal | 40 L | |
| Engine oil, w/filter | 5 qt | 4.7 L | |
| Hydraulic reservoir capacity | 9.2 gal | 35 L |
NOISE LEVEL
| NOISE LEVEL | |||
|---|---|---|---|
| Operator ear sound pressure | 89 dBA | ||
| Sound power | 100 dBA |
BATTERY
| BATTERY | |||
|---|---|---|---|
| SAE reserve capacity rating | 110 min | ||
| SAE cold crank @ 0°F (-18°C) | 800 amps | ||
| Electrical system | 12V |
